LG 86TR3DJ-B
86" UHD IR Multi Touch Interactive Whiteboard
LG 86" UHD IR Multi Touch Interactive Whiteboard
#86TR3DJ-B
Our Price: $4,900.00
Click here to jump to more pricing!
Overview:
LG UHD IR Multi Touch Interactive Whiteboard
- UHD (3,840x2,160) IPS Display
- IR Multi touch point (Max 20 points/Max 10 writing)
- Dual Pen and Dual Color
- AirClass, ScreenShare Pro, & Bluetooth Connectivity,
- Integrated OPS slot (PC not included)
Features:
Multi Touch
The TR3DJ series can simultaneously use up to 20 points of multi touch. This function offers a lifelike board touch experience and makes collaboration much easier.
Enhanced Visibility with Low Parallax
With 1mm gap between the screen and tempered glass, which supports low parallax, The TR3DJ series can offer precise touch and excellent writing experience.
Dual Pen & Dual Color
The stylus pen comes in two different colors and with two different tip sizes of 3mm and 8mm. The dual pens enable users to write or draw simultaneously.
Easy Writing Experience
The TR3DJ series allows you to write and annotate on all sources, so your writing experience can be easy and satisfying.
Air Class
Air Class supports connecting up to 30 students and offers interactive meetings for mobile devices on the same network, providing a variety of tools such as voting, answering, and sharing project texts. Air Class is easily accessible from the TR3DJ's main toolbar.
Built-in OPS Slot
The TR3DJ series supports OPS slots, allowing you to easily and conveniently mount an OPS device at the back of the digital board without the hassle of connecting to an external desktop, offering you more expanded functions.
Specifications:
|
PANEL |
MODEL |
86TR3DJ |
75TR3DJ |
65TR3DJ |
|---|---|---|---|---|
|
Screen Size |
86" |
75" |
65" |
|
|
Panel Technology |
IPS |
IPS |
IPS |
|
|
Back Light Type |
Direct |
Direct |
Direct |
|
|
Aspect Ratio |
16:9 |
16:9 |
16:9 |
|
|
Native Resolution |
3840 x 2160 (UHD) |
3840 x 2160 (UHD) |
3840 x 2160 (UHD) |
|
|
Refresh Rate |
60Hz |
60Hz |
60Hz |
|
|
Brightness (Typ) |
350 nits |
350 nits |
350 nits |
|
|
Contrast Ratio |
1200:1 |
1200:1 |
1200:1 |
|
|
Color gamut |
NTSC 68% |
NTSC 68% |
NTSC 68% |
|
|
Viewing Angle (H x V) |
178° X 178° |
178° X 178° |
178° X 178° |
|
|
Color Depth |
10bit, 1.07Billion colors |
10bit, 1.07Billion colors |
10bit, 1.07Billion colors |
|
|
Response Time |
8ms (G to G) |
8ms (G to G) |
8ms (G to G) |
|
|
Surface Treatment(Haze) |
Anti Glare, 7H(Mohs) |
Anti Glare, 7H(Mohs) |
Anti Glare, 7H(Mohs) |
|
|
Lifetime Operation |
30,000 Hrs |
30,000 Hrs |
30,000 Hrs |
|
|
Operation Hours (Hours/Day) |
16/7 |
16/7 |
16/7 |
|
|
Portrait / Landscape |
Landscape Only |
Landscape Only |
Landscape Only |
|
|
TOUCH |
Available object size for touch |
³3 mm |
³3 mm |
³3 mm |
|
Reponse Time |
£60 ms (Android) £100 ms (Windows) |
£60 ms (Android) £100 ms (Windows) |
£60 ms (Android) £100 ms (Windows) |
|
|
Accuracy |
±2 mm |
±2 mm |
±2 mm |
|
|
Interface |
USB 2.0 |
USB 2.0 |
USB 2.0 |
|
|
Protection Glass Thickness |
4T (Anti-Glare) |
4T (Anti-Glare) |
4T (Anti-Glare) |
|
|
Protection Glass Trans- mission |
87% |
87% |
87% |
|
|
Operating System Support |
Windows XP/7/8/10, Linux, Mac, Android (WindowsXP/Linux/Mac support one point touch) |
Windows XP/7/8/10, Linux, Mac, Android (WindowsXP/Linux/Mac support one point touch) |
Windows XP/7/8/10, Linux, Mac, Android (WindowsXP/Linux/Mac support one point touch) |
|
|
Multi touch point |
Max 20 Points |
Max 20 Points |
Max 20 Points |
|
|
SOUND |
Built-in Speakers |
10W x 2 |
10W x 2 |
10W x 2 |
|
CONNECTIVITY |
HDMI In |
Yes (3), HDCP2.2/1.4 |
Yes (3), HDCP2.2/1.4 |
Yes (3), HDCP2.2/1.4 |
|
Analog RGB In |
Yes (1) |
Yes (1) |
Yes (1) |
|
|
Audio In |
Yes (1) |
Yes (1) |
Yes (1) |
|
|
RS232C In |
Yes (1) |
Yes (1) |
Yes (1) |
|
|
RJ45 (LAN) |
Yes (1) |
Yes (1) |
Yes (1) |
|
|
USB In |
USB3.0 Type A(3) USB2.0 Type A(3) |
USB3.0 Type A(3) USB2.0 Type A(3) |
USB3.0 Type A(3) USB2.0 Type A(3) |
|
|
Audio Out |
Optical (1) |
Optical (1) |
Optical (1) |
|
|
Touch USB Out |
Yes (2) |
Yes (2) |
Yes (2) |
|
|
MECHANICAL |
Bezel Color |
Black |
Black |
Black |
|
Bezel Width |
18.9 / 18.9 / 18.9 / 45.7 mm |
18.9 / 18.9 / 18.9 / 45.7 mm |
18.9 / 18.9 / 18.9 / 45.7 mm |
|
|
Weight |
148.7 lbs / 67.5 kg |
117.1 lbs / 53.1 kg |
85.4 lbs / 38.8 kg |
|
|
Shipping Weight |
190.9 lbs / 86.6 kg |
154.0 lbs / 69.9 kg |
106.9 lbs / 48.5 kg |
|
|
Monitor Dimension (W x H x D) |
77.0 x 45.7 x 3.4 in 1957 × 1160 × 87 mm |
67.3 x 40.2 x 3.4 in 1710 × 1020 × 87 mm |
58.6 x 35.3 x 3.4 in 1489 × 897 × 87 mm |
|
|
Carton Dimensions (W x H x D) (Box outer size) |
83.1 x 50.5 x 11.0 in 2112 × 1283 × 280 mm |
73.2 x 44.9 x 11.0 in 1860 × 1140 × 280 mm |
64.1 x 39.6 x 8.2 in 1628 × 1005 × 208 mm |
|
|
Handle |
Yes |
Yes |
Yes |
|
|
Stand |
No |
No |
No |
|
|
VESATM Standard Mount Interface |
800 x 600mm |
800 x 400mm |
600 x 400mm |
|
|
Operation Temperature |
32° to 104° F / 0° to 40° C |
32° to 104° F / 0° to 40° C |
32° to 104° F / 0° to 40° C |
|
|
Operation Humidity |
10% to 80% |
10% to 80% |
10% to 80% |
|
|
OPS type compatible |
Yes (Slot) |
Yes (Slot) |
Yes (Slot) |
|
|
OPS Power built in |
Yes |
Yes |
Yes |
|
|
FEATURES |
Internal Memory |
16 GB |
16 GB |
16 GB |
|
Built-in Wi-Fi |
Yes (Removable) |
Yes |
Yes |
|
|
Power Indicator |
Yes |
Yes |
Yes |
|
|
Local Key Operation |
Yes |
Yes |
Yes |
|
|
Fanless Design |
Yes |
Yes |
Yes |
|
|
Android Version |
Android 8.0 |
Android 8.0 |
Android 8.0 |
|
|
Screen Share |
Yes (Screenshare pro) |
Yes (Screenshare pro) |
Yes (Screenshare pro) |
|
|
POWER |
Power Supply |
100-240 Vac, 50/60 Hz |
100-240 Vac, 50/60 Hz |
100-240 Vac, 50/60 Hz |
|
Power Type |
Built-In Power |
Built-In Power |
Built-In Power |
|
|
Power Consumption (Typ) |
370W |
260W |
180W |
|
|
Power Consumption (Max) |
|
350W |
300W |
|
|
Power Consumption (Off) |
Less than 0.5W |
Less than 0.5W |
Less than 0.5W |
|
|
"WARRANTY & OTHER" |
Warranty |
3 Year Limited |
3 Year Limited |
3 Year Limited |
|
FCC (Regulatory) |
Class "A" |
Class "A" |
Class "A" |
|
|
CE (Regulatory) |
Yes |
Yes |
Yes |
|
|
ErP (Environmental) |
Yes |
Yes |
Yes |
|
|
Basic Accessories |
Power Cord (3m), USB Cable (5m), HDMI Cable (3m), Writing Pen (x2), User Man- ual, Quick Start Guide, Remote Control (batteries incl.), Wi-Fi module |
Power Cord (3m), USB Cable (5m), HDMI Cable (3m), Writing Pen (x2), User Man- ual, Quick Start Guide, Remote Control (batteries incl.), Wi-Fi module |
Power Cord (3m), USB Cable (5m), HDMI Cable (3m), Writing Pen (x2), User Man- ual, Quick Start Guide, Remote Control (batteries incl.), Wi-Fi module |
Views:
Documentation:
Download the LG UHD IR Multi Touch Interactive Whiteboard - TR3DJ-B Series Datasheet (.PDF)
Pricing Notes:
- Pricing and product availability subject to change without notice.
Our Price: $4,900.00
