LG 60UL3E
60" Ultra HD Signage Display
LG 60UL3E 60" Ultra HD Signage Display
Sorry, this product is no longer available, please contact us for a replacement.
Click here to jump to more pricing!
Overview:
Clear Color Expression of UHD Content
The UL3E series delivers Ultra HD content in vivid colors and with fine details, giving audiences a clearer viewing experience in a large, beautiful display. With its ease of management and compatibility with automated control systems like Crestron and Extron, the UL3E series can help employees fully concentrate on critical work tasks instead of taking extra time to manage device connections.
- Size: 60"
- True Color, Wide View
- Vivid Color Details with Ultra HD
- LG Simple Editor
- USB Data Cloning
- Compatibility with Automated Control Systems
- Compatibility with Video Conferencing Systems
Features:
Superior Picture Quality
True Color, Wide View
LG IPS panel features a wide viewing angle to deliver clear content regardless of where meeting participants are seated. Each pixel in the IPS panel reproduces image colors true-to-life, without distortion.
Vivid Color Details with Ultra HD
The UHD resolution allows users to view details even when zooming in on the display, with four times higher definition than FHD. The UL3E ensures stable UHD video playback with HEVC(High Efficiency Video Coding).
PC-less Content Management
LG Simple Editor
Users can create content easily using embedded templates that provide customizable elements. Once a playlist is set, LG Simple Editor supports it to be distributed to several displays via network connection or USB plug-in.
USB Data Cloning
USB data cloning makes managing multiple displays more efficient for optimal operation, since users don’t have to set up each display one by one. Once users copy data to a USB in one display, it will be easily distributed to others through a USB plug-in.
High Compatibility
Compatibility with AV Control System
The UL3E series has been certified Crestron Connected for a higher level of compatibility with professional AV controls to achieve seamless integration and automated control1), boosting business management efficiency.
Compatibility with Video Conference System
For the optimum visual meeting, the UL3E has certified its compatibility1) with Cisco Spark Room Kits. The picture quality is automatically adjusted for video conference, reducing a time to coordinate multiple devices.
Easy Management
Real-Time Remote Monitoring
In case of malfunctions or errors, real-time remote care is available. When an error occurs, a notification can be sent through the SNMP (Simple Network Management Protocol) protocol.
Power & Network in One Line
WOL (Wake-on-LAN) enables users to send a message through network to turn on displays. This greatly simplifies the installation and maintenance processes as only a single wire is required for power and network connection.
Specifications:
60UL3E Specifications | |
---|---|
Panel | |
Screen Size | 60" |
Panel Technology | VA |
Aspect Ratio | 16 : 9 |
Native Resolution | 3,840 x 2,160 (UHD) |
Brightness | 400 nits |
Contrast Ratio | 4,000:1 |
Viewing Angle (H x V) | 176° x 176° |
Response Time | 8.8 ms (G to G) |
Surface Treatment | Low Haze 5% |
Life Time (Min.) | 30,000 hours |
Guaranteed Operating Hour | 16 Hours |
Orientation | Landscape |
Connectivity | |
Input | HDMI (2), USB 2.0 (2) |
Output | Audio (Optical) |
External Control | RS232C In, RJ45 In |
Physical Specification | |
Bezel Color | Cramic Black |
Bezel Width | 17.7 mm (T), 17.5 mm (L/R), 21.4 mm (B) |
Monitor Dimension (W x H x D) | 53.9” x 31.3” x 3.5” / 1,368 x 796 x 89.1 mm (w/Speaker) |
Weight (Head) | 42.8 lbs / 19.4 kg |
Carton Dimensions (W x H x D) | 58.7” x 34.6” x 7.5” / 1,492 x 880 x 190 mm |
Packed Weight | 55.8 lbs / 25.3 kg |
VESA Standard Mount Interface | 300 mm x 300 mm |
Special Features | |
Special Features | Local Key Operation, Auto Brightness Sensor, webOS (TV UI, w/o SCAP), Lock Mode, Setting Data Cloning (USB), SNMP (Ver, 1.4) Crestron Connected, Cisco No Touch Set-up, DPM, Power on Status, Wake on LAN, HDMI-CEC3 , Built-in Speaker (10W×2) |
Environmental Conditions | |
Operating Temperature Range | 32° F to 104° F / 0°C to 40°C |
Operating Humidity Range | 10 % to 80 % |
Power | |
Power Supply | 100-240 V~, 50/60 Hz |
Power Type | Built-In Power |
Power Consumption - Typ.. | 112 W |
Power Consumption - Max. | 205 W |
Certification | |
Safety | UL |
EMC | FCC Class A |
ErP / Energy Star | Energy Star 7.0 |
Software Compatibility | |
Content Management Software | SuperSign CMS |
Control and Monitoring Software | SuperSign Control/Control+ |
Accessory | |
Basic | Remote Controller (Batteries Included), Power Cord, QSG, Safety Manual |
Warranty | |
Warranty | 3 Year Limited Warranty |
Documentation:
Download the LG Ultra HD Signage - UL3E Series Datasheet (.PDF)
